Product Details
Strength-to-weight, brake authority, and chain durability — engineered together. The BLVS018-020 answers the work generated by plants where load capacity, brake authority, and chain durability all matter. Equipped with a 0.33 HP motor and industrial-grade construction throughout, it handles full-capacity operation across long production cycles. Lifetime warranty coverage stands behind every certified lift.
Features
- Heavy-duty 265 lbs. working load handles the lifts professional overhead lifting environments actually demand.
- Industrial-grade 20 feet lift range — expanding the lift envelope without sacrificing capacity rating.
- Industrial-grade 0.33 HP single-phase drive — running quieter and cooler than equivalent open-frame designs, built for manufacturing cells.
- Built-in overload protection handles the load-bearing safety net for protecting both equipment and operator from over-pull.
- Double-pawl Weston brake — holding load in either direction with no drift or slip, sized for controlled descent across the lift range.
- Heat-treated, proof-loaded chain delivers cycle-count durability for the strength-to-weight ratio industrial lifting demands.
Specifications
- SKUJT9-104002
- Classification / CertificationANSI/ASME B30.16, ANSI/ASME HST-1 Standard
- Duty Cycle30 H3
- Hook Mount Headroom15.75 in.
- Lift20 ft.
- Lift ControlWireless
- Lifting Speed0-10 / 41 FPM
- Maximum Number Of Starts Per Hr180
- Maximum On Time Min Hr15
- Net Weight39
- Old Material Number104002
- Overload ProtectionNo
- Product TypeTools & Equipment
- Prop 65Cancer and Reproductive Harm
- SAP Gross Weight47
- UPC731325854497
- WarrantyTwo Years
- Motor HP0.33 HP
- Motor PhaseSingle
- Motor Voltage115 V
