Product Details
Frame rigidity meets blade-speed flexibility. Engineered around production sawing across hardwoods, softwoods, and metal stock, the JTAS-12-DX earns its place. Equipped with a 5 HP motor and industrial-grade construction throughout, it handles full-capacity operation across long production cycles. Engineered for production cycles, warrantied for the long run.
Features
- Professional-grade 5 HP motor with sealed bearings — delivering full-rated power to the cut, not the brush dust across manufacturing cells.
- Tolerance-grade saw frame provides blade alignment for blade alignment under sustained cutting.
- Heavy-duty tilting table — delivering angle accuracy precision work expects, engineered for miter and bevel cuts that defeat fixed-table saws.
- Production-grade cutting envelope supports workpiece sizes for the workpiece sizes production sawing actually runs.
- Industrial-grade cast iron main castings deliver rigidity for tolerance retention across years of cycles.
- Engineered hardened power-train components — holding tolerance well past the warranty period, engineered for tolerance retention across years of cycles.
Specifications
- SKUJT9-708546PK
- Arbor Size1 in.
- Arbor Speed4300 RPM
- Assembled Dimensions50 x 84-1/2 x 40 in.
- Base Size50 x 84-1/2 in.
- Blade Diameter12 in.
- Blade Length12 in.
- Blade Size (In.)12 in.
- Blade Speed3450 RPM
- Cutting Capacity - Height4 in.
- Dust Port Outside Diameter4 in.
- Height40 in.
- Horse Power5 HP
- Input Power230 V 1 Ph
- Maximum Depth Of Cut4 in.
- Maximum Diameter Of Dado8 in.
- Maximum Rip Left Of Blade14 in.
- Maximum Width Of Dado13/16 in.
- Miter Gauge TypeT-Slot with Stops
- Model NumberJTAS-12-DX
- Motor Amps20 A
- Motor HP5 HP
- Motor PhaseSingle
- Motor Voltage230 V
- Old Material Number708546PK
- Overall Assembled (Bow Lowered)50 x 84-1/2 x 40 in.
- Prewired Voltage230 V
- Product TypeMachines
- Prop 65Cancer and Reproductive Harm
- Recommended Circut Size Amp30 A
- Required Cfm350 - 350 CFM
- SAP Gross Weight669.3
- SAP Net weight623
- Style TypeCabinet
- Table Front Of Saw Blade At Maximum Depth of Cut12 in.
- Table Height34 in.
- Table Size31-1/2 x 24 in.
- Table TypeCast Iron
- UPC731325226447
- WarrantyFive Years
