Product Details
Built for the cuts that production fabrication actually generates. The ECB-1833DMEVS-460 answers the work generated by fabrication shops running daily cuts. Equipped with a 7.5 HP motor and industrial-grade construction throughout, it handles full-capacity operation across long production cycles. JET warranty coverage stands behind every cut.
Features
- Premium-grade 7.5 HP motor with sealed bearings — holding speed under load when lighter motors stall across industrial shop floors.
- 50 - 300 blade speed — matching cut velocity to material density.
- Working-grade frame construction holds blade alignment for the cutting authority industrial fabrication demands.
- Professional-grade tilting table — delivering angle accuracy precision work expects, engineered for the angled cuts production fabrication actually runs.
- Precision-rated cutting envelope handles workpiece sizes for the cut-length envelope industrial sawing requires.
- Tolerance-grade cast iron tables earn their place for the structural stability shop work demands.
Specifications
- SKUJT9-891175
- Assembled Dimensions110 x 75 x 83 in.
- Bed Height39-3/8 in.
- Blade Size (In.)1.61 x 0.051 x 240 in.
- Blade Speed50 - 300
- Coolant Pump Motor1/8 HP, 460 V, 3 PH
- Drive TypeEVS
- Hydraulic Motor Hp1 HP
- Input Power230 V 3 Ph
- Miter Angle Motor1/5 HP, 460 V, 3 Ph
- Model NumberECB-1833DMEVS-460
- Motor HP7.5 HP
- Motor PhaseThree
- Motor Voltage460 V
- Old Material Number891175
- Prewired Voltage460 V
- Product TypeMachines
- Prop 65Cancer and Reproductive Harm
- Rectangle At 45 Degrees18 x 20-13/16 in.
- Rectangle At 60 Degrees18 x 14-29/32 in.
- Rectangle At 90 Degrees18 x 31-1/2 in.
- Round Capacity At 45 Degrees18 in.
- Round Capacity At 60 Degrees18 in.
- Round Capacity At 90 Degrees15 in.
- SAP Gross Weight5,500
- SAP Net weight5,060
- Square At 45 Degrees18 x 18 in.
- Square At 60 Degrees15 x 15 in.
- Square At 90 Degrees18 x 18 in.
- Throat Depth18 in.
- UPC731325868531
- WarrantyThree Years
- Wheel Diameter22-53/64 in.
