Product Details
Strength-to-weight, brake authority, and chain durability — engineered together. The 3SS-3C-20 answers the work generated by facilities running ANSI/ASME-compliant overhead lifting. Equipped with a 2 HP motor and industrial-grade construction throughout, it handles full-capacity operation across long production cycles. Backed by the JET warranty.
Features
- 6600 lbs. working load — passing third-party load testing before shipment, certified for capacity ratings inspectors verify on regulated job sites.
- Engineered 20 feet lift envelope — fitting the overhead applications industrial shops actually run across production overhead work.
- Continuous-duty 2 HP induction drive — holding speed under load when lighter motors stall.
- Tolerance-grade overload protection works whether shop power is on or off for safety regulated lifting requires.
- Double-pawl Weston brake — splitting load mechanically across both pawls — no electronics, no batteries, no weak link, sized for the safety-net redundancy regulated lifting demands.
- Heat-treated, proof-loaded chain handles cycle-count durability for the wear pattern production rigging actually generates.
Specifications
- SKUJT9-332000
- Capacity6600 lbs.
- Classification / CertificationANSI/ASME B30.16, ANSI/ASME HST-1 Standard
- Duty Cycle30 H3
- Hook Mount Headroom41.333 in.
- Lift20 ft.
- Lift ControlWired
- Lifting Speed8.3 FPM
- Maximum Number Of Starts Per Hr180
- Maximum On Time Min Hr18
- Old Material Number332000
- Overload ProtectionNo
- Product TypeTools & Equipment
- Prop 65Cancer and Reproductive Harm
- SAP Gross Weight235
- SAP Net weight216
- Shipyard HooksNo
- UPC662755906374
- WarrantyTwo Years
- Motor HP2 HP
- Motor PhaseThree
- Motor Voltage460 V
