Product Details
Production-grade sawing for shops that need it daily. The AB-12 answers the work generated by production sawing across hardwoods, softwoods, and metal stock. Equipped with a 5 HP motor and industrial-grade construction throughout, it handles full-capacity operation across long production cycles. JET warranty coverage stands behind every cut.
Features
- Tolerance-grade 5 HP drive matches consistent torque for mixed-material work envelopes.
- 4200 RPM cutting speed — covering the material library production sawing runs across professional sawing environments.
- Working-grade frame construction holds blade alignment for blade-tracking accuracy production sawing requires.
- Tilting-table geometry covers angled cuts for miter-and-bevel work in one setup.
- Shop-rated cutting envelope handles workpiece sizes for the cut-length envelope industrial sawing requires.
- Working-grade cast iron trunnion castings dampen harmonics across industrial machining.
Specifications
- SKUJT9-414240
- Abrasive TypeDisc
- Amp Draw (amps)15 A
- Assembled Dimensions57 x 23.6 x 69.7 in.
- Bed Height38 in.
- Blade Diameter12 in.
- Blade Size (In.)12 in.
- Blade Speed4200 RPM
- Capacity Rectangular2.7 x 4.7
- Capacity Round3.5 @ 45 Deg./3.9 @ 90 Deg.
- Capacity Square3.5 x 3.5
- Drive TypePulley & Belt
- Height38 in.
- Horse Power5 HP
- Input Power230 V 3 Ph
- Maximum Vise Opening7.5 in.
- Model NumberAB-12
- Motor Amps14 A
- Motor HP5 HP
- Motor PhaseThree
- Motor Voltage230 V
- Old Material Number414240
- Prewired Voltage230 V
- Product TypeMachines
- Prop 65Cancer and Reproductive Harm
- Rectangle At 45 Degrees3-11/16 x 3-1/2 in.
- Rectangle At 90 Degrees2-11/16 x 4-11/16 in.
- Rectangle Capacity 45 Left3-11/16 x 3-1/2 in.
- Rectangle Capacity 45 Right3-11/16 x 3-1/2 in.
- Round Capacity At 90 Degrees11777 in.
- SAP Gross Weight478
- SAP Net weight315
- Solid Rectangle Capacity At 45 Degrees2.7 x 3.5 in.
- Solid Round Capacity At 45 Degrees3.5 in.
- Solid Round Capacity At 90 Degrees3.9 in.
- Solid Square Capacity At 45 Degrees3.1 x 3.1 in.
- Solid Square Capacity At 90 Degrees3.5 x 3.5 in.
- Style TypeAbrasive Saw
- UPC731325517231
- WarrantyTwo Years
