Product Details
Frame rigidity meets blade-speed flexibility. The CS-275 was sized for production sawing across hardwoods, softwoods, and metal stock. Equipped with a 1.5 HP motor and industrial-grade construction throughout, it handles full-capacity operation across long production cycles. JET warranty coverage stands behind every cut.
Features
- Industrial 1.5 HP induction motor: holding RPM under cutting load that would stall lighter motors, designed for industrial shop floors.
- 54/108 RPM cutting speed — delivering the cutting velocity production fabrication requires across professional sawing environments.
- Production-spec frame construction holds blade alignment for the structural mass production sawing depends on.
- Precision table tilt mechanism delivers angle accuracy for miter and bevel cuts that defeat fixed-table saws.
- Wide cutting envelope — delivering working capacity production sawing actually demands.
- Premium-grade cast iron reference surfaces earn their place for the structural authority production work demands.
Specifications
- SKUJT9-414226
- Blade Diameter11 in.
- Blade Size (In.)275 mm
- Blade Speed54/108 RPM
- CoatingPowder Coat
- Cutting Capacity - Height5.2 in.
- Horse Power1.5 HP
- Input Power115/230 V 1 Ph
- Maximum Vise Opening4 in.
- Model NumberCS-275
- Motor HP1.5 HP
- Motor PhaseThree
- Motor Voltage230 V
- Old Material Number414226
- Product TypeMachines
- Prop 65Cancer and Reproductive Harm
- SAP Gross Weight400
- SAP Net weight350
- Solid Rectangle Capacity At 45 Degrees2-3/16 x 2 in.
- Solid Rectangle Capacity At 90 Degrees3-3/32 x 2 in.
- Solid Round Capacity At 45 Degrees23455 in.
- Solid Round Capacity At 90 Degrees23455 in.
- Solid Square Capacity At 45 Degrees2-3/16 x 2-3/16 in.
- Solid Square Capacity At 90 Degrees2-1/2 x 2-1/2 in.
- Style TypeFerrous
- Tubing Rectangle At 45 Degrees2-3/16 x 2 in.
- Tubing Rectangle At 90 Degrees3-3/32 x 2 in.
- Tubing Round At 45 Degrees23455 in.
- Tubing Round At 90 Degrees23455 in.
- UPC662756127846
- WarrantyTwo Years
