Product Details
Where the cut starts: blade speed, blade geometry, and rigid frame in one tool. The JTAS-10DX-530 fits production sawing across hardwoods, softwoods, and metal stock — and the cycle counts they generate. Equipped with a 5 HP motor and industrial-grade construction throughout, it handles full-capacity operation across long production cycles. Engineered for production cycles, warrantied for the long run.
Features
- 5 HP, 230V single-phase induction motor — delivering consistent torque without brushwear, sized for mixed-material work envelopes.
- Blade speed of 4300 RPM matches the cutting velocity for the cutting envelope production fabrication generates.
- Welded steel frame keeps the saw planted — delivering frame authority production sawing actually requires.
- Heavy-duty tilting table — delivering the angle envelope production cutting demands, engineered for angle accuracy production work expects.
- Continuous-duty cutting envelope delivers workpiece sizes for the stock library production fabrication actually generates.
- Industrial-grade cast iron main castings deliver rigidity for the operating envelope precision cutting generates.
Specifications
- SKUJT9-708676PK
- Arbor Size5/8 in.
- Arbor Speed4300 RPM
- Assembled Dimensions34 x 29 x 42 in.
- Base Size34 x 29 in.
- Blade Diameter10 in.
- Blade Length10 in.
- Blade Size (In.)10 in.
- Blade Speed4300 RPM
- Cutting Capacity - Height3 in.
- Dust Port Outside Diameter4 in.
- Height42 in.
- Horse Power5 HP
- Input Power230 V 1 Ph
- Maximum Depth Of Cut3 in.
- Maximum Diameter Of Dado8 in.
- Maximum Rip Left Of Blade12 in.
- Maximum Width Of Dado13/16 in.
- Miter Gauge TypeDeluxe
- Model NumberJTAS-10DX-530
- Motor Amps18 A
- Motor HP5 HP
- Motor PhaseSingle
- Motor Voltage230 V
- Old Material Number708676PK
- Overall Assembled (Bow Lowered)34 x 29 x 42 in.
- Prewired Voltage230 V
- Product TypeMachines
- Prop 65Cancer and Reproductive Harm
- Recommended Circut Size Amp20 A
- Required Cfm350 - 350 CFM
- SAP Gross Weight490
- SAP Net weight490
- Style TypeCabinet
- Table Front Of Saw Blade At Maximum Depth of Cut10 in.
- Table Height34 in.
- Table Size29 x 20 in.
- Table TypeCast Iron
- UPC662755941061
- WarrantyFive Years
