Product Details
Production-grade milling for the cuts that hold tolerance through long cycles. The EVS-949 was sized for shops that hold tolerance through full production runs. Equipped with a 3 HP motor and industrial-grade construction throughout, it handles full-capacity operation across long production cycles. Engineered for the cycle counts production work actually generates.
Features
- The 3 HP induction motor — transmitting power without the maintenance brush-motor designs require for the cycle counts industrial use generates.
- Industrial 9 in. x 49 in. table — delivering the fixture mounting flexibility production work demands, sized for the fixture library production shops already keep.
- Industrial-grade 5-inch spindle travel — covering the depth-of-cut envelope production milling generates across industrial drilling.
- Operating range of 60 - 5,000 RPM covers the cuts for the speed range production work generates.
- Industrial Meehanite bed castings — holding true under loads that warp commercial-grade iron across tolerance-grade machine work.
- Hardened and ground feed gears transmit power for the dimensional stability precision work demands.
Specifications
- SKUJT9-894321
- Assembled Dimensions64 x 66 x 84 in.
- Collet Size1/8 - 7/8 in.
- Digital Readout3 Axis Acu-Rite 203(Quill)
- Distance Spindle to Column (Max.)21-2/5 in.
- Distance Spindle to Column (Min.)6 in.
- Head Movement90 Deg. (R & L), 45 Deg. (F & B)
- Maximum Distance Spindle To Table18-3/4 in.
- Number of Axis3 (Quill)
- Old Material Number894321
- Power FeedX-Axis/Y-Axis/Z-Axis (JET)
- Product TypeMachines
- Prop 65Cancer
- Quill Diameter3-3/8 in.
- Quill Down Feed Rate0.0015 - 0.003 - 0.006 IPR
- Range Of Spindle Speeds60 - 5000 RPM
- SAP Gross Weight2,450
- SAP Net weight2,200
- Spindle TaperR8
- Spindle Taper X TpiR8
- Spindle Travel5 in.
- Style TypeVariable Speed
- T-Slot Centers2-1/2 in.
- T-Slots Number And Size3 and 5/8 in.
- Table Cross Travel12 in.
- Table Longitudal Travel36 in.
- Table Size9 x 49 in.
- Travel Of Knee16 in.
- Travel Of Ram14 in.
- UPC731325287332
- WarrantyThree Years
- Work Table Weight Capacity750 lbs
- Input Power230 V 3 Ph
- Motor HP3 HP
- Motor PhaseThree
- Motor Voltage230 V
- Amp Draw (amps)19 A
