Product Details
Engineered for the long cuts and the tight tolerances. The EVS-949 was sized for fabrication and tool-room work that demands tolerance. Equipped with a 3 HP motor and industrial-grade construction throughout, it handles full-capacity operation across long production cycles. Backed by JET warranty coverage.
Features
- Tolerance-grade 3 HP motor with sealed bearings — delivering full-rated power to the cut, not the brush dust across manufacturing cells.
- 9 in. x 49 in. working surface covers the fixture-and-vise library for the workholding patterns production milling depends on.
- Precision-rated 5-inch spindle travel — delivering vertical reach production work actually requires across production fabrication.
- Heavy-duty 60 - 5,000 RPM range — delivering the speed envelope production cutting demands.
- Certified Meehanite column castings resist wear and deflection for the structural rigidity tolerance-grade work demands.
- Precision-hardened and ground power-feed gears hold tolerance — delivering the dimensional stability precision work measures.
Specifications
- SKUJT9-894346
- Assembled Dimensions64 x 66 x 84 in.
- Collet Size1/8 - 7/8 in.
- Digital Readout3 Axis Acu-Rite 303(Knee)
- Distance Spindle to Column (Max.)21-2/5 in.
- Distance Spindle to Column (Min.)6 in.
- Head Movement90 Deg. (R & L), 45 Deg. (F & B)
- Maximum Distance Spindle To Table18-3/4 in.
- Number of Axis3 (Knee)
- Old Material Number894346
- Power FeedX-Axis (JET)
- Product TypeMachines
- Prop 65Cancer
- Quill Diameter3-3/8 in.
- Quill Down Feed Rate0.0015 - 0.003 - 0.006 IPR
- Range Of Spindle Speeds60 - 5000 RPM
- SAP Gross Weight2,450
- SAP Net weight2,200
- Spindle TaperR8
- Spindle Taper X TpiR8
- Spindle Travel5 in.
- Style TypeVariable Speed
- T-Slot Centers2-1/2 in.
- T-Slots Number And Size3 and 5/8 in.
- Table Cross Travel12 in.
- Table Longitudal Travel36 in.
- Table Size9 x 49 in.
- Travel Of Knee16 in.
- Travel Of Ram14 in.
- UPC731325287585
- WarrantyThree Years
- Work Table Weight Capacity750 lbs
- Input Power230 V 3 Ph
- Motor HP3 HP
- Motor PhaseThree
- Motor Voltage230 V
- Amp Draw (amps)19 A
