Product Details
Built around the spindle, the table, and the operator who runs them. The EVS-949 is built for shops that hold tolerance through full production runs. Equipped with a 3 HP motor and industrial-grade construction throughout, it handles full-capacity operation across long production cycles. Backed by JET warranty coverage.
Features
- Production-spec 3 HP three-phase induction motor delivers torque for sustained-load operation production work demands.
- Industrial 9 in. x 49 in. table — expanding the workholding envelope without sacrificing rigidity, sized for the fixture library production shops already keep.
- Premium-grade 5-inch spindle travel — covering the depth-of-cut envelope production milling generates across production milling.
- Engineered 60 - 5,000 RPM range — eliminating the speed compromises older designs forced.
- Premium Meehanite bed castings earn their place for tolerance retention through years of cycles.
- Heat-treated and surface-ground spindle bearings resist wear across precision production work.
Specifications
- SKUJT9-894300
- Assembled Dimensions64 x 66 x 84 in.
- Collet Size1/8 - 7/8 in.
- Digital ReadoutNo
- Distance Spindle to Column (Max.)21-2/5 in.
- Distance Spindle to Column (Min.)6 in.
- Head Movement90 Deg. (R & L), 45 Deg. (F & B)
- Maximum Distance Spindle To Table18-3/4 in.
- Number of AxisNone
- Old Material Number894300
- Power FeedX-Axis
- Product TypeMachines
- Prop 65Cancer
- Quill Diameter3-3/8 in.
- Quill Down Feed Rate0.0015 - 0.003 - 0.006 IPR
- Range Of Spindle Speeds60 - 5000 RPM
- SAP Gross Weight2,450
- SAP Net weight2,200
- Spindle TaperR8
- Spindle Taper X TpiR8
- Spindle Travel5 in.
- Style TypeVariable Speed
- T-Slot Centers2-1/2 in.
- T-Slots Number And Size3 and 5/8 in.
- Table Cross Travel12 in.
- Table Longitudal Travel36 in.
- Table Size9 x 49 in.
- Travel Of Knee16 in.
- Travel Of Ram14 in.
- UPC731325287127
- WarrantyThree Years
- Work Table Weight Capacity750 lbs
- Input Power230 V 3 Ph
- Motor HP3 HP
- Motor PhaseThree
- Motor Voltage230 V
- Amp Draw (amps)19 A
