Product Details
Engineered for the abrasive cycle counts production work actually generates. The IBG-12 is built for shops where surface finish gets shipped, not reworked. Equipped with a 2 HP motor and industrial-grade construction throughout, it handles full-capacity operation across long production cycles. Industrial-grade construction, industrial-grade warranty.
Features
- Brushless 2 HP induction motor design means decades of service across industrial shop floors.
- Engineered belt tension — handling the abrasive media library production finishing uses.
- Continuous-duty belt design handles the abrasive cycle counts for the surface-area envelope production sanding requires.
- Tolerance-grade disc geometry supports flat grinding for the cycle counts production grinding generates.
- Engineered tilting table — delivering the angle accuracy precision finishing requires across production grinding.
- Cast iron construction in the support castings — resisting deflection under sustained cutting forces.
Specifications
- SKUJT9-578012
- Abrasive TypeAluminum Oxide
- Assembled Dimensions27.56 x 18.1 x 18.1 in.
- Disc Diameter12 in.
- Disc Speed1800 RPM
- Dust Port Outside Diameter2-1/2 in.
- Horse Power2 HP
- Input Power230 V 1 Ph
- Model NumberIBG-12
- Motor Amps8 / 4 A
- Motor HP2 HP
- Motor PhaseSingle
- Motor TypeEnclosed
- Motor Voltage230 V
- Mounting Hole Diameter7/16 in.
- Mounting Hole Spacing8-3/4 in.
- Noise Level Db at 3Ft80 dB
- Old Material Number578012
- Prewired Voltage230 V
- Product TypeMachines
- Prop 65Cancer and Reproductive Harm
- Recommended Circut Size Amp15 A
- Required Cfm350 - 350 CFM
- SAP Gross Weight272
- SAP Net weight238
- Shaft Diameter1-1/4 in.
- Spindle Diameter1-1/4 in.
- Spindle Speed1800 RPM
- UPC731325242645
- WarrantyTwo Years
- Wheel Diameter12 in.
- Wheel Grits36 / 60
- Wheel Speed RPM1800 RPM
- Wheel Width2 in.
