8" Vari. Speed Industrial Grinder, 1HP, 115/230V 1PH(IBG-8VS)
8" Vari. Speed Industrial Grinder, 1HP, 115/230V 1PH(IBG-8VS)
8" Vari. Speed Industrial Grinder, 1HP, 115/230V 1PH(IBG-8VS)
8" Vari. Speed Industrial Grinder, 1HP, 115/230V 1PH(IBG-8VS)

8" Vari. Speed Industrial Grinder, 1HP, 115/230V 1PH(IBG-8VS)

Stock Number: JT9-578208

0 Reviews

No reviews yet.

  • 1 HP, 115/230V, single-phase
  • Heavy-duty belt drive
  • Cast iron base
  • Precision-balanced disc
BUY NOW
Fetching Data...

Product Details

Material removal sized for production, finish quality sized for delivery. The IBG-8VS was sized for industrial finishing environments running long abrasive cycles. Equipped with a 1 HP motor and industrial-grade construction throughout, it handles full-capacity operation across long production cycles. Engineered for production finishing cycles, warrantied for the duty.

Features

  • Brushless induction design at 1 HP delivers reliable output for the cycle counts industrial use generates.
  • Precision-rated abrasive belt drive — delivering consistent abrasive contact across professional finishing environments.
  • Heavy-duty belt drive — delivering consistent abrasive contact.
  • Disc-grinding architecture — delivering disc-grinding authority production finishing requires across production grinding.
  • Tilting-table geometry covers angle work for angled finishing in one setup.
  • Heavy cast iron structural components — earning their place through sheer mechanical authority, engineered for vibration dampening welded steel can't match.

Specifications

  • SKU
    JT9-578208
  • Abrasive Type
    Aluminum Oxide
  • Assembled Dimensions
    23-1/2 x 8 x 10-9/16 in. (590 x 205 x 268 mm)
  • Disc Diameter
    8 in.
  • Disc Speed
    900-3600 RPM
  • Dust Port Outside Diameter
    2-1/2 in.
  • Horse Power
    1 HP
  • Input Power
    115/230 V 1 Ph
  • Model Number
    IBG-8VS
  • Motor Amps
    15 A
  • Motor HP
    1 HP
  • Motor Phase
    Single
  • Motor Type
    Enclosed
  • Motor Voltage
    115/230 V
  • Mounting Hole Diameter
    7/16 in.
  • Mounting Hole Spacing
    8-1/2 in.
  • Noise Level Db at 3Ft
    75 dB
  • Old Material Number
    578208
  • Prewired Voltage
    115 V
  • Product Type
    Machines
  • Prop 65
    Cancer and Reproductive Harm
  • Recommended Circut Size Amp
    15 A
  • Required Cfm
    350 - 350 CFM
  • SAP Gross Weight
    72
  • SAP Net weight
    66
  • Shaft Diameter
    5/8 in.
  • Spindle Diameter
    5/8 in.
  • Spindle Speed
    900-3600 RPM
  • UPC
    731325698398
  • Warranty
    Two Years
  • Wheel Diameter
    8 in.
  • Wheel Grits
    36 / 60
  • Wheel Speed RPM
    900-3600 RPM
  • Wheel Width
    1 in.
