Product Details
Where surface quality gets decided. Engineered around industrial finishing environments running long abrasive cycles, the IBGB-248VS earns its place. Equipped with a 1 HP motor and industrial-grade construction throughout, it handles full-capacity operation across long production cycles. Engineered for production finishing cycles, warrantied for the duty.
Features
- 1 HP single-phase induction motor sized without bogging down on full-width passes.
- Production-grade belt drive delivers abrasive contact for the cycle counts production finishing generates.
- Belt geometry was sized for the abrasive cycle counts production sanding generates.
- Precision-balanced disc — running true at full RPM.
- Precision-rated tilting table — extending the working envelope across industrial finishing.
- Working-grade cast iron frame castings dampen harmonics across the work envelope this machine targets.
Specifications
- SKUJT9-577248
- Abrasive Grit80
- Abrasive TypeBelt
- Assembled Dimensions21-1/4 x 24-3/4 x 13-15/16 in., 21-1/4 x 12-9/32 x 25-29/32 in.
- Base Size9-1/2 x 8-1/16 in.
- Belt Size48 x 2 in.
- Belt Speed1178 - 4712 SFPM
- Belt Table Size4-11/32 x 2-15/16 in.
- Belt Tilt Range45 Deg. down
- Disc Diameter8 in.
- Dust Port Outside Diameter2 in.
- Horse Power1.5 HP
- Input Power115/230 V 1 Ph
- Model NumberIBGB-248VS
- Motor Amps8 / 4 A
- Motor HP1 HP
- Motor PhaseSingle
- Motor TypeEnclosed
- Motor Voltage115/230 V
- Noise Level Db at 3Ft75 dB
- Number Ports2
- Old Material Number577248
- Prewired Voltage115 V
- Product TypeMachines
- Prop 65Cancer and Reproductive Harm
- Recommended Circut Size Amp20 A
- Required Cfm400 - 400 CFM
- SAP Gross Weight86.5
- SAP Net weight80
- Shaft Diameter5/8 in.
- UPC731325773156
- WarrantyTwo Years
- Wheel Diameter8 in.
- Wheel Grits36
- Wheel Speed RPM900-3600 RPM
- Wheel Width1 in.
