Product Details
Production-grade grinding and sanding for the work that gets shipped. The J-4300A was sized for finishing work that has to pass QA review. Equipped with a 1.5 HP motor and industrial-grade construction throughout, it handles full-capacity operation across long production cycles. Industrial-grade construction, industrial-grade warranty.
Features
- Continuous-duty 1.5 HP induction drive — running quieter and cooler than equivalent open-frame designs.
- Engineered abrasive belt drive — matching the surface-finish envelope production sanding generates across industrial sanding environments.
- Factory-tested belt design handles the abrasive cycle counts for the surface-area envelope production sanding requires.
- Premium-grade disc geometry handles flat grinding for the production work this machine targets.
- Adjustable tilting table — delivering the angle accuracy precision finishing requires.
- Shop-rated cast iron structural components dampen harmonics across industrial tool-room work.
Specifications
- SKUJT9-414600
- Abrasive TypeBelt
- Assembled Dimensions25-1/2 x 16 x 43 in., 19 x 16 x 57-1/2 in.
- Belt Size6 x 48 in.
- Belt Speed2850 SFPM
- Belt Table Size7-3/8 x 14-3/4 in.
- Belt Tilt Range20 Deg. Up, 45 Deg. Down
- Disc Speed2850 RPM
- Dust Port Outside Diameter3 in.
- Horse Power1.5 HP
- Input Power115/230 V 1 Ph
- Miter Gauge Groove3/8 x 3/4 in.
- Model NumberJ-4300A
- Motor Amps12.6 A
- Motor HP1.5 HP
- Motor PhaseSingle
- Motor Voltage115/230 V
- Old Material Number414600
- Platen Size6-1/4 x 14-3/4 in.
- Prewired Voltage115/230 V
- Product TypeMachines
- Prop 65Cancer and Reproductive Harm
- Recommended Circut Size Amp12/6.3 A
- SAP Gross Weight290
- SAP Net weight215
- Style TypeBelt
- UPC662755111372
- WarrantyTwo Years
