20" EVS Drill Press w/ Power Downfeed, Clutch, 1.5HP, 230V 3PH(JDPE-20EVSC-PDF)
20" EVS Drill Press w/ Power Downfeed, Clutch, 1.5HP, 230V 3PH(JDPE-20EVSC-PDF)

20" EVS Drill Press w/ Power Downfeed, Clutch, 1.5HP, 230V 3PH(JDPE-20EVSC-PDF)

Stock Number: JT9-354251

0 Reviews

No reviews yet.

  • MT-3 spindle taper
  • 6" spindle travel
BUY NOW

Product Details

From small-shop hole-making to tool-room precision. The JDPE-20EVSC-PDF answers the work generated by industrial drilling environments running through-hole and deep-hole work. Rigid column, hardened spindle bearings, and precision quill assembly deliver repeatable hole-making run after run. JET warranty coverage and the service network keep production drilling running.

Features

  • Production-grade MT-3 spindle interface — fitting the tooling library production shops already maintain.
  • Generous 6-inch quill travel handles deep-hole and through-hole production work for the working depth precision cutting requires.
  • Industrial cast iron base castings resist deflection for finish quality consistency across speeds.
  • Heat-treated and surface-ground spindle gears resist wear across production cycles.
  • CSA/cUS listed construction — delivering the safety documentation procurement actually expects, certified for facility safety compliance requirements.
  • Tolerance-grade capacity rating — delivering the duty cycle production demands across production environments.

Specifications

  • SKU
    JT9-354251
  • Assembled Dimensions
    32-3/5 x 22-2/3 x 70-25/64 in.
  • Base Size
    17.7 x 25-1/2 in., 14-3/16 x 13 in.
  • Chuck Size
    0.5 x 20 in.
  • Collet Size
    4 in.
  • Distance Column to Spindle
    26-1/2 in.
  • Drilling Capacity Cast Iron
    1.25 in.
  • Drilling Capacity Mild Steel
    1.125 in.
  • Drills to Center of Circle
    10 in.
  • Input Power
    115 V 1 Ph
  • Inverter Type
    JET Exclusive
  • Inverter Type Power Source
    2HP/115V/1PH
  • Model Number
    JDPE-20EVSC-PDF
  • Motor Amps
    4.6 A
  • Motor HP
    1.5 HP
  • Motor Phase
    Three
  • Motor Voltage
    230 V
  • Old Material Number
    354251
  • Prewired Voltage
    230 V
  • Product Type
    Machines
  • Prop 65
    Cancer and Reproductive Harm
  • Quill Diameter
    2.16 in.
  • Range Of Spindle Speeds
    Variable
  • SAP Gross Weight
    582
  • SAP Net weight
    493
  • Spindle Distance To Base
    48-1/4 in.
  • Spindle Distance To Table Max
    46.85 in.
  • Spindle Taper X Tpi
    MT3
  • Spindle Travel
    6 in.
  • Spindle Travel Manual
    5 in.
  • Style Type
    Variable Speed
  • Swing
    19-11/16 in.
  • T-Slots Number And Size
    2, 1/2 in.
  • Table Size
    16-1/2 x 18-1/2 in.
  • Table Tilt (L, R, C)
    45 Deg.
  • Tapping Capacity Mild Steel
    5/8 in.
  • UPC
    731325789621
  • Warranty
    Two Years
