26" x 80" Lg Spindle Bore Gear Head Lathe w/ Acu-Rite 203 & Taper Attachment Kit, 15HP, 230/460V 3PH(GH-2680ZH)

The JET GH-2680ZH 26x80 Large Spindle Bore ZH Industrial Gear Head Lathe is built for shops that need 26" of swing and dependable, all-day turning performance without cutting corners on operator safety.

The GH-2680ZH's 80" distance between centers and 4-1/2" spindle bore give operators the reach and through-capacity needed for longer shafts and bar stock passed directly through the headstock.

The geared head is turned by a 15 HP Three-Phase motor, offering 12 spindle speeds spanning 10-1000 RPM for flexibility across materials and cut depths.

As configured here, the GH-2680ZH includes a Acu-Rite 203 digital readout for precise, at-a-glance positioning that reduces reliance on manual dial counting, and a taper attachment kit for accurate, repeatable taper turning independent of the compound slide.

Standard industrial safety features include:

• Integrated coolant system
• UL 987 certified electrical system
• Electronic chuck key holder to reduce the risk of a key left in the chuck
• Foot brake for rapid spindle stopping
• Chuck guard at the point of operation
• Full-length splash guard

A pre-shipment inspection and 2-year parts and labor warranty stand behind every GH-2680ZH, backed by JET's nationwide authorized service network.

From heavy industrial fabrication to oil and gas equipment manufacturing, the GH-2680ZH is a fit anywhere large-diameter roll and shaft turning demand accuracy and uptime.

OPTIONAL ACCESSORIES

• Collet Closer (Optional)
