8" x 36" Mill w/ 3-Axis NMS800 DRO (Q), 1.5HP, 230V 3PH(JVM-836-3)
8" x 36" Mill w/ 3-Axis NMS800 DRO (Q), 1.5HP, 230V 3PH(JVM-836-3)

8" x 36" Mill w/ 3-Axis NMS800 DRO (Q), 1.5HP, 230V 3PH(JVM-836-3)

Stock Number: JT9-691184

0 Reviews

No reviews yet.

  • 1.5 HP, 230V, three-phase
  • 7-7/8" x 35-3/4" table
  • R-8 spindle taper
  • 5" spindle travel
BUY NOW
Fetching Data...

Product Details

Engineered for the long cuts and the tight tolerances. The JVM-836-3 is built for shops that hold tolerance through full production runs. Equipped with a 1.5 HP motor and industrial-grade construction throughout, it handles full-capacity operation across long production cycles. Built for the long cycles that define production milling.

Features

  • Heavy-duty 1.5 HP induction motor handles working speed under load — delivering production-grade power output.
  • Premium-grade 7-7/8 in. x 35-3/4 in. table accommodates production setups for the fixture-and-vise setups operators already use.
  • Industrial-grade 5-inch spindle travel — putting deep-hole work in reach without secondary setups across production milling.
  • Continuous-duty 120 - 1,550 RPM range — delivering operator-side speed control.
  • Professional-grade Meehanite main castings — resisting wear and deflection, sized for stability where commercial-grade iron warps.
  • Engineered hardened knee gears — holding feed rates without backlash compensation, engineered for the working precision shops measure in tenths.

Specifications

  • SKU
    JT9-691184
  • Air Powered Drawbar
    No
  • Assembled Dimensions
    55 x 52 x 77 in.
  • Collet Size
    1/8 - 7/8 in.
  • Digital Readout
    3-Axis Newall NMS800
  • Distance Spindle to Column (Max.)
    15-3/4 in.
  • Distance Spindle to Column (Min.)
    5-1/4 in.
  • Head Movement
    90 Deg. (L&R)
  • Input Power
    230 V 3 Ph
  • Maximum Distance Spindle To Table
    13-3/4 in.
  • Model Number
    JVM-836-3
  • Motor HP
    1.5 HP
  • Motor Phase
    Three
  • Motor Voltage
    230 V
  • Noise Level Db at 3Ft
    75 dB
  • Number of Spindle Speeds
    10
  • Old Material Number
    691184
  • Power Feed
    No
  • Product Type
    Machines
  • Prop 65
    Cancer and Reproductive Harm
  • Quill Diameter
    3-3/8 in.
  • Quill Down Feed Rate
    .0015 - .003 - .006 IPR
  • Range Of Spindle Speeds
    120 - 1550 RPM
  • SAP Gross Weight
    1,630
  • SAP Net weight
    1,630
  • Spindle Taper
    R8
  • Spindle Taper X Tpi
    R8
  • Spindle Travel
    5 in.
  • Style Type
    Step Pulley
  • T-Slot Centers
    2-1/2 in.
  • T-Slots Number And Size
    3 and 5/8 in.
  • Table Cross Travel
    9-1/2 in.
  • Table Longitudal Travel
    22-1/4 in.
  • Table Longitudal Travel With Powerfeed
    18 in.
  • Table Size
    7-7/8 x 35-3/4 in.
  • Travel Of Knee
    14 in.
  • Travel Of Ram
    10-1/2 in.
  • UPC
    662755513992
  • Warranty
    Two Years
  • Work Table Weight Capacity
    500 lbs
