52" Proshop Tablesaw w/ Cast wings, 1.75HP, 115V(JPS-10-52C)
52" Proshop Tablesaw w/ Cast wings, 1.75HP, 115V(JPS-10-52C)
52" Proshop Tablesaw w/ Cast wings, 1.75HP, 115V(JPS-10-52C)
52" Proshop Tablesaw w/ Cast wings, 1.75HP, 115V(JPS-10-52C)
52" Proshop Tablesaw w/ Cast wings, 1.75HP, 115V(JPS-10-52C)
52" Proshop Tablesaw w/ Cast wings, 1.75HP, 115V(JPS-10-52C)
52" Proshop Tablesaw w/ Cast wings, 1.75HP, 115V(JPS-10-52C)
52" Proshop Tablesaw w/ Cast wings, 1.75HP, 115V(JPS-10-52C)
52" Proshop Tablesaw w/ Cast wings, 1.75HP, 115V(JPS-10-52C)
52" Proshop Tablesaw w/ Cast wings, 1.75HP, 115V(JPS-10-52C)
52" Proshop Tablesaw w/ Cast wings, 1.75HP, 115V(JPS-10-52C)

52" Proshop Tablesaw w/ Cast wings, 1.75HP, 115V(JPS-10-52C)

Stock Number: JT9-725001K

0 Reviews

No reviews yet.

  • 1.75 HP, 115V, single-phase
  • Heavy-duty welded steel frame
  • Adjustable blade tracking
BUY NOW
Fetching Data...

Product Details

Engineered for clean cuts across hardwoods, softwoods, and metal stock. The JPS-10-52C answers the work generated by fabrication shops running daily cuts. Equipped with a 1.75 HP motor and industrial-grade construction throughout, it handles full-capacity operation across long production cycles. Industrial-grade construction backed by the JET service network.

Features

  • Sealed 1.75 HP induction motor protects against the dust, chips, and humidity of high-volume working environments.
  • Professional-grade saw frame supports blade alignment for the structural mass production sawing depends on.
  • Industrial tilting table — handling miter and bevel cuts in one setup, engineered for the angled cuts production fabrication actually runs.
  • Premium-grade cutting envelope provides workpiece sizes for the cut-length envelope industrial sawing requires.
  • Industrial cast iron support castings resist deflection for the structural stability shop work demands.
  • Continuous-duty hardened gears — running quieter, cooler, and with less vibration than stock-grade alternatives, engineered for power transmission consistency across cycles.

Specifications

  • SKU
    JT9-725001K
  • Arbor Size
    5/8 in.
  • Arbor Speed
    4000 RPM
  • Assembled Dimensions
    82 x 40 x 43 in.
  • Base Size
    82 x 40 in.
  • Blade Diameter
    10 in.
  • Blade Length
    10 in.
  • Blade Size (In.)
    10 in.
  • Blade Speed
    4000 RPM
  • Cutting Capacity - Height
    3 in.
  • Dust Port Outside Diameter
    4 in.
  • Height
    43 in.
  • Horse Power
    1.75 HP
  • Input Power
    115 V 1 Ph
  • Maximum Depth Of Cut
    3.125 in.
  • Maximum Diameter Of Dado
    8 in.
  • Maximum Rip Left Of Blade
    13-1/2 in.
  • Maximum Width Of Dado
    13/16 in.
  • Miter Gauge Type
    T-Slot with Stops
  • Model Number
    JPS-10-52C
  • Motor Amps
    7.4 A
  • Motor HP
    1.75 HP
  • Motor Phase
    Single
  • Motor Voltage
    115 V
  • Old Material Number
    725001K
  • Overall Assembled (Bow Lowered)
    82 x 40 x 43 in.
  • Prewired Voltage
    115 V
  • Product Type
    Machines
  • Prop 65
    Cancer and Reproductive Harm
  • Recommended Circut Size Amp
    20 A
  • Required Cfm
    350 - 350 CFM
  • SAP Gross Weight
    352.45
  • SAP Net weight
    325.95
  • Style Type
    Contractor
  • Table Front Of Saw Blade At Maximum Depth of Cut
    8.81 in.
  • Table Height
    34-3/4 in.
  • Table Size
    20 x 27 in.
  • Table Type
    Cast Iron
  • UPC
    731325727494
  • Warranty
    Five Years
