Product Details
Engineered for the loads that production environments actually move. Engineered around plants where load capacity, brake authority, and chain durability all matter, the TS200-460-020 KIT earns its place. Equipped with a 5 HP motor and industrial-grade construction throughout, it handles full-capacity operation across long production cycles. Backed by JET warranty coverage and ANSI/ASME-verified construction.
Features
- Production-spec 4400 lbs rating — delivering working capacity production overhead lifting requires.
- The 10 feet lift envelope was sized for the vertical work envelope production rigging targets.
- Professional-grade 5 HP drive provides consistent torque for the working loads daily production generates.
- Engineered overload sensing — delivering mechanical overload sensing built into the load path, sized for the over-pull protection production overhead work demands.
- Self-engaging Weston brake delivers the load-holding redundancy for the safety-net redundancy regulated lifting demands.
- Alloy steel load chain — matching the strength-to-weight ratio overhead lifting demands across regulated lifting environments.
Specifications
- SKUJT9-144007K
- Capacity4400 lbs.
- Classification / CertificationANSI/ASME B30.16, ANSI/ASME HST-1 Standard
- Duty Cycle40/20 H4
- Hook Mount Headroom38.2 in.
- Lift10 ft.
- Lift ControlWired
- Lifting Speed8 / 32 FPM
- Maximum Number Of Starts Per Hr240
- Maximum On Time Min Hr30
- Old Material Number144007K
- Overload ProtectionNo
- Product TypeTools & Equipment
- Prop 65Cancer and Reproductive Harm
- SAP Gross Weight375
- SAP Net weight320
- Shipyard HooksNo
- UPC731325879933
- WarrantyTwo Years
- Motor HP5 HP
- Motor PhaseThree
- Motor Voltage460 V
