Product Details
Frame rigidity meets blade-speed flexibility. The VBS-18MWEVS was sized for production environments where blade speed and frame rigidity both count. Equipped with a 2 HP motor and industrial-grade construction throughout, it handles full-capacity operation across long production cycles. Industrial-grade construction backed by the JET service network.
Features
- Industrial-grade 2 HP three-phase drive — delivering full-rated power to the cut, not the brush dust, built for industrial production lines.
- 100-3,6003600 SFPM cutting speed — expanding the cutting envelope across production fabrication.
- Precision-rated frame construction holds blade alignment for blade-tracking accuracy production sawing requires.
- Precision table tilt mechanism delivers angle accuracy for the angle work production fabrication generates.
- Heavy-duty cutting envelope supports workpiece sizes for the stock library production fabrication actually generates.
- Cast iron main castings dampen vibration for the rigidity precision work demands.
Specifications
- SKUJT9-414428
- Assembled Dimensions36 x 34 x 80 in.
- Bed Height37.5 in.
- Blade Diameter18 in.
- Blade Length150 in.
- Blade Size (In.)150 in.
- Blade Speed100-3,6003600 sfpm
- Blade Width1/8 - 1-1/4 in.
- Cutting Capacity - Height4-1/8 in.
- Drive TypeEVS
- Dust Port Outside Diameter4 in.
- Height37 in.
- Height Capacity Max16 in.
- Horse Power2 HP
- Input Power230 V 3 Ph
- Miter Gauge Groove3/4 x 3/8 in.
- Model NumberVBS-18MWEVS
- Motor HP2 HP
- Motor PhaseThree
- Motor Voltage230 V
- Old Material Number414428
- Overall Assembled (Bow Lowered)36 x 34 x 80 in.
- Prewired Voltage230 V
- Product TypeMachines
- Prop 65Cancer and Reproductive Harm
- Recommended Circut Size Amp20 A
- SAP Gross Weight572
- SAP Net weight502
- Table Height37 in.
- Table Size27-1/4 x 20 in.
- Table Tilt (L, R, C)5, 45 Deg.
- Throat Depth18 in.
- UPC731325868616
- WarrantyTwo Years
- Wheel Diameter18 in.
